SKF UCF 205/H – 25 mm Flange Bearing Unit

SKF UCF 205/H – 25 mm Flange Bearing Unit

The SKF UCF 205/H is a complete, ready-to-mount flange bearing unit designed to provide robust support for rotating shafts. This assembly consists of a deep groove ball insert bearing housed within a durable, four-bolt cast iron housing. Its design, which includes set screws for secure shaft locking and seals for contamination resistance, makes it a reliable and easy-to-install solution for a wide range of industrial applications.

—

Quick Navigation

• About This Bearing Unit
• Technical Specifications
• Key Features & Benefits

—

About This Bearing Unit

This product is a **flange bearing unit**, also known as a pillow block unit, which combines a bearing insert with a mounting housing. The **UCF** designation is a common nomenclature for these units: “**UC**” refers to the deep groove ball bearing insert, and “**F**” indicates the housing type, which is a square, four-bolt flange. The unit is secured to the shaft using two **set screws** in the extended inner ring, providing a simple and effective locking mechanism. This type of mounted unit is ideal for applications where the shaft needs to be supported at a right angle to the mounting surface, such as in conveyor systems, fans, and agricultural machinery.

—

Technical Specifications

• Manufacturer: SKF
• Part Number: UCF 205/H
• Part Type: Flange Ball Bearing Unit
• Dimensions:
  • Shaft Diameter (d): 25 mm
  • Center Distance Between Bolt Holes (J): 70 mm
  • Housing Overall Width (A): 27 mm
  • Overall Unit Width (T): 35.8 mm
• Housing Type: Four-Bolt Square Flange (UCF)
• Housing Material: Cast Iron
• Weight: 0.72 kg
• Also Known As: UCF 205H, UCF205, 25 mm Pillow Block

—

Key Features & Benefits

• Ready-to-Mount: The complete unit is pre-assembled and easily bolted to a machine frame, simplifying the installation process.
• Secure Shaft Locking: The set-screw locking mechanism provides a firm and reliable grip on the shaft.
• Contamination Resistance: The bearing is sealed to protect against dust and moisture, extending its service life.
• Versatile Use: Suitable for a variety of general-purpose applications due to its ability to handle combined radial and axial loads.
