SKF NU 2220 ECP/C3 – 100 mm Cylindrical Roller Bearing

SKF NU 2220 ECP/C3 – 100 mm Cylindrical Roller Bearing

The SKF NU 2220 ECP/C3 is a high-performance, single-row cylindrical roller bearing designed to handle very heavy radial loads. The NU designation indicates a non-locating or “floating” bearing, which allows for axial displacement of the shaft. With an optimized internal design for increased load capacity, a durable polyamide cage, and a larger-than-normal C3 internal clearance, it is a reliable choice for demanding applications with high loads and operating temperatures.

—

Quick Navigation

• About This Bearing
• Applications
• Why ROMA Industrial Company
• Technical Specifications
• Key Features & Benefits

—

About This Bearing

This product is a single-row cylindrical roller bearing. The NU designation signifies a non-locating design, meaning the inner ring can move axially relative to the outer ring. This feature is crucial in applications where thermal expansion or contraction of the shaft must be accommodated without creating stress on the bearing. The ECP suffix indicates an optimized internal geometry (E) for enhanced load capacity and a polyamide cage (CP), which is lightweight and allows for higher speeds. The C3 clearance is a larger-than-normal internal clearance that prevents the bearing from seizing under high-temperature or interference-fit conditions.

—

Applications

This cylindrical roller bearing is suitable for a variety of heavy-duty applications with high radial loads, including:

• Industrial Gearboxes
• Electric Motors
• Pumps and Compressors
• Conveyor Systems
• Machine Tools

—

Why ROMA Industrial Company

ROMA Industrial is your trusted partner for a full range of industrial supplies across categories like Motion Control & Mechatronics, Electrical & Automation, and Fluid Power & Control. We are committed to providing top-tier products and service to keep your operations running smoothly. We partner with world-class shipping providers like FedEx, DHL, and UPS to ensure fast and reliable delivery worldwide. We accept returns to fulfill your satisfaction and accept variable payments methods including PayPal, credit cards, and more. We are a supplier in Europe, USA, and Saudi Arabia.

—

Technical Specifications

• Manufacturer: SKF
• Part Number: NU 2220 ECP/C3
• Bearing Type: Cylindrical Roller Bearing
• Dimensions:
  • Inner Diameter (d): 100 mm
  • Outer Diameter (D): 180 mm
  • Width (B): 34 mm
• Bore Type: Cylindrical
• Cage Material: Polyamide (Nylon)
• Internal Clearance: C3
• Dynamic Load Rating: 287 kN
• Static Load Rating: 295 kN
• Limiting Speed: 5,000 r/min
• Reference Speed: 7,100 r/min
• Weight: N/A

—

Key Features & Benefits

• High Radial Load Capacity: Designed to withstand very heavy radial forces, making it ideal for robust industrial machinery.
• Non-Locating Design: Allows for axial displacement of the shaft, accommodating thermal expansion without creating stress.
• Enhanced Durability: The optimized internal design and polyamide cage contribute to a longer service life and higher speeds.
• Resistant to Seizing: The C3 internal clearance ensures stable operation in high-temperature applications.
