SKF UCP 214 – 70 mm Pillow Block Bearing Unit

SKF UCP 214 – 70 mm Pillow Block Bearing Unit

The SKF UCP 214 is a complete, ready-to-mount pillow block bearing unit, offering a robust and self-contained solution for shaft support. This assembly features a bearing insert housed within a solid cast-iron pillow block housing, designed for easy mounting on a flat surface. Its set-screw locking mechanism ensures a firm grip on the shaft, while the sealed design protects the bearing from contaminants, making it a reliable and low-maintenance choice for a wide range of industrial applications.

—

Quick Navigation

• About This Bearing Unit
• Technical Specifications
• Key Features & Benefits

—

About This Bearing Unit

This product is a pillow block bearing unit, which is a type of mounted bearing assembly. The UCP designation is a common nomenclature: “UC” refers to the deep groove ball bearing insert, and “P” indicates a pillow block housing. The bearing insert has a spherical outer ring that allows it to accommodate some initial shaft misalignment. This unit secures to the shaft using two set screws in the extended inner ring. This design is ideal for applications where the shaft needs to be supported parallel to the mounting surface. The entire unit is pre-lubricated and sealed, ensuring long-term, maintenance-free operation in challenging environments.

—

Technical Specifications

• Manufacturer: SKF
• Part Number: UCP 214
• Part Type: Pillow Block Bearing Unit
• Dimensions:
  • Bore Diameter (d): 70 mm
  • Center Height (H): 79.4 mm
  • Total Length (L): 266 mm
• Housing Type: Pillow Block
• Housing Material: Cast Iron
• Dynamic Load Rating (C): 62.4 kN
• Static Load Rating (C0): 44 kN
• Weight: 7.1 kg
• Also Known As: UCP214, 70 mm Pillow Block Bearing

—

Key Features & Benefits

• Simplified Installation: The pre-assembled unit is easy to mount on a flat surface with two bolts, reducing assembly time and effort.
• Secure Shaft Locking: The set-screw locking mechanism provides a firm and reliable grip on the shaft, preventing slippage.
• Contamination Resistance: The sealed bearing inside the housing protects against dust and moisture, extending the bearing’s service life.
• Misalignment Compensation: The spherical outer ring of the insert bearing allows the unit to accommodate initial shaft misalignment, reducing stress on the assembly.
