SKF UCF 204/H – 20 mm Flange Bearing Unit

SKF UCF 204/H – 20 mm Flange Bearing Unit

The SKF UCF 204/H is a complete, ready-to-mount flange bearing unit designed to provide robust support for rotating shafts. This assembly consists of a deep groove ball bearing housed within a durable, four-bolt cast iron housing. Its design, which includes set screws for secure shaft locking and seals for contamination resistance, makes it a reliable and easy-to-install solution for a wide range of industrial applications.

—

Quick Navigation

• About This Bearing Unit
• Technical Specifications
• Key Features & Benefits

—

About This Bearing Unit

This product is a flange bearing unit, also known as a pillow block unit, which combines a bearing insert with a mounting housing. The UCF designation is a common nomenclature for these units: “UC” refers to the deep groove ball bearing insert, and “F” indicates the housing type, which is a square, four-bolt flange. The unit is secured to the shaft using two set screws in the extended inner ring, providing a simple and effective locking mechanism. The H suffix in the part number indicates a design for higher contamination resistance. This type of mounted unit is ideal for applications where the shaft needs to be supported at a right angle to the mounting surface, such as in conveyor systems, fans, and agricultural machinery.

—

Technical Specifications

• Manufacturer: SKF
• Part Number: UCF 204/H
• Part Type: Flange Ball Bearing Unit
• Dimensions:
  • Bore Diameter (d): 20 mm
  • Center Distance Between Bolt Holes (J): 64 mm
  • Overall Unit Width (T): 33.3 mm
• Housing Type: Four-Bolt Square Flange (UCF)
• Housing Material: Cast Iron
• Dynamic Load Rating (C): 12.7 kN
• Static Load Rating (C0): 6.55 kN
• Weight: 0.56 kg
• Also Known As: UCF 204H, UCF204, 20 mm Pillow Block

—

Key Features & Benefits

• Ready-to-Mount: The complete unit is pre-assembled and easily bolted to a machine frame, simplifying the installation process.
• Secure Shaft Locking: The set-screw locking mechanism provides a firm and reliable grip on the shaft.
• Contamination Resistance: The sealed bearing and housing design protect against dust and moisture, extending the bearing’s service life.
• Versatile Use: Suitable for a variety of general-purpose applications due to its ability to handle combined radial and axial loads.
