SKF 32213 J2/Q – Tapered Roller Bearing

SKF 32213 J2/Q – 65 mm Tapered Roller Bearing

The SKF 32213 J2/Q is a single-row tapered roller bearing designed to handle a combination of high radial and axial loads. As part of the SKF Explorer class, it offers enhanced load capacity and a longer service life. Its separable design allows for the inner ring and outer ring to be mounted separately, simplifying installation and dismounting in various industrial applications.

—

Quick Navigation

• About This Bearing
• Technical Specifications
• Key Features & Benefits

—

About This Bearing

This product is a single-row tapered roller bearing, distinguished by its conical inner and outer rings, and conical rollers. This design enables it to support a combination of heavy radial loads and axial loads in one direction. The bearing’s separable design, with the inner ring and roller assembly (cone) separate from the outer ring (cup), simplifies the mounting and dismounting process. The 32213 part number provides its basic dimensions, and the J2/Q suffix indicates key features. J2 specifies a pressed steel cage, while Q signifies that it is part of the high-performance SKF Explorer class, which is engineered for superior load-carrying capacity and durability.

—

Technical Specifications

• Manufacturer: SKF
• Part Number: 32213 J2/Q
• Bearing Type: Tapered Roller Bearing
• Dimensions:
  • Bore Diameter (d): 65 mm
  • Outer Diameter (D): 120 mm
  • Total Width (T): 32.75 mm
• Dynamic Load Rating (C): 186 kN
• Static Load Rating (C0): 193 kN
• Limiting Speed: 5,600 r/min
• Cage Material: Pressed Steel (J2)
• Weight: 1.5 kg
• Also Known As: 32213 J2Q, SKF Explorer 32213, 65x120x32.75 mm Bearing

—

Key Features & Benefits

• High Load Capacity: Designed to carry a combination of heavy radial and axial loads.
• Enhanced Performance: As an SKF Explorer bearing, it offers a longer service life and higher performance than a standard bearing.
• Separable Design: The two-part construction (cup and cone) simplifies mounting and dismounting, which facilitates maintenance and replacement.
• Durable Construction: The robust design and pressed steel cage ensure a long and reliable service life.
