FAG H313 – Withdrawal Sleeve for 60 mm Shafts

FAG H313 – Withdrawal Sleeve for 60 mm Shafts

The FAG H313 is a precision withdrawal sleeve used to mount and dismount tapered-bore bearings on a cylindrical shaft. It is an essential accessory for securing bearings like spherical roller bearings. The sleeve simplifies the installation process, creating a tight and secure fit between the bearing and the shaft. For dismounting, the sleeve’s external thread allows it to be easily pulled out, releasing the bearing without causing damage to the shaft or bearing components.

—

Quick Navigation

• About This Withdrawal Sleeve
• Technical Specifications
• Key Features & Benefits

—

About This Withdrawal Sleeve

This product is a withdrawal sleeve, a key accessory for mounting bearings with a tapered bore. The sleeve is first positioned on a cylindrical shaft. The tapered-bore bearing is then mounted by pushing it up the tapered outer surface of the sleeve. This creates a secure, interference fit. The **H313** designation specifies its dimensions and compatibility, designed for use with a 60 mm shaft. A critical design feature is the external thread, which is used during the dismounting process. By using a locknut or a specialized dismounting tool, the sleeve can be pulled away from the bearing, which releases the tight fit and allows for the bearing to be easily and safely removed from the shaft.

—

Technical Specifications

• Manufacturer: FAG (part of the Schaeffler Group)
• Part Number: H313
• Product Type: Withdrawal Sleeve
• Intended Shaft Diameter: 60 mm
• Compatible Bearing Series: e.g., 222, 232
• Mounting Type: Tapered Bore
• Dismounting Method: Threaded Puller
• Weight: N/A
• Also Known As: H-313, 60 mm Shaft Sleeve, Tapered Bore Adapter

—

Key Features & Benefits

• Secure Mounting: Ensures a tight and precise fit for tapered-bore bearings on a cylindrical shaft.
• Simplified Dismounting: The threaded design allows for easy removal of the bearing, preventing damage.
• Versatile Compatibility: Designed for use with various self-aligning bearings, such as spherical roller bearings.
• Essential Accessory: A crucial component for proper installation and maintenance of tapered-bore bearings.
