DUPLOMATIC OLEODINAMICA DSE3-C16/08SB/11N-D12K1 – 12V DC 4/2-Way Hydraulic Valve

DUPLOMATIC OLEODINAMICA DSE3-C16/08SB/11N-D12K1 – 12V DC 4/2-Way Hydraulic Valve

The DUPLOMATIC OLEODINAMICA DSE3-C16/08SB/11N-D12K1 is a high-performance hydraulic directional control valve with a single solenoid and spring return, designed for precise control in demanding fluid power systems. The valve’s schematic indicates a 4/2-way function with a spring return, meaning the valve returns to a default position when its solenoid is de-energized. It features a high pressure rating of 350 bar and is ideal for applications requiring a powered shift to one position and a spring-driven return.

Quick Navigation

• Key Features
• About this Valve Function
• Technical Specifications
• Applications
• Why Choose ROMA Company?

Key Features

• 4/2-Way Function: The valve provides two operating positions with a spring return to a default state.
• Single-Solenoid Actuation: The solenoid on the right, labeled ‘b’, shifts the spool when an electrical signal is applied.
• Spring Return: When the solenoid is de-energized, the spring on the left automatically pushes the spool back to its default position.
• High Pressure Rating: Capable of withstanding a maximum pressure of 350 bar, ensuring durability and performance.
• 12V DC Solenoid: Operates on a standard 12V DC control voltage, common in mobile and industrial applications.

About this Valve Function

The diagram shows a 4/2-way, single-solenoid directional control valve with a spring return.

• 4/2-Way: The valve has four ports (P, T, A, B) and two operating positions (the two squares).
• Single-Solenoid: The rectangle on the right, labeled ‘b’, represents the valve’s solenoid. When an electrical signal is sent to the solenoid, it shifts the spool to the active position.
• Spring Return: The zigzag line on the left represents a spring. When the solenoid is de-energized, the spring pushes the spool back to the default position.

Flow Paths:

• Default Position (Solenoid de-energized): In the left square, the arrows indicate that fluid flows from P (pressure) to B (work port), while the A port is connected to T (tank).
• Active Position (Solenoid energized): When the solenoid shifts the spool to the right, the flow paths change. Fluid now flows from P to A, while B is connected to T.

Technical Specifications

• Manufacturer: DUPLOMATIC OLEODINAMICA
• Part Number: DSE3-C16/08SB/11N-D12K1
• Product Type: Hydraulic Directional Control Valve
• Type: Directional Valve
• Function: 4/2-way
• Pressure: 350 bar (Max)
• Operating Method: Solenoid
• Solenoid Count: Single Solenoid
• Voltage: 12V DC

Applications

This DUPLOMATIC hydraulic valve is a fundamental component in many fluid power systems for controlling actuators, including:

• Industrial Hydraulic Systems
• Mobile Machinery and Equipment
• Cylinder and Actuator Control
• Clamping and Press Applications
